The Steel Supply Company provides steel wedges to Steel Fabricators, Concrete and Masonry Contractors and the general construction trades. Often the customers' requirements can be met with stock sizes as shown in our catalog.
Steel Manufacturing Blog: Keeping it Steel
When manufacturing made to order steel wedges there are a number of ways it can be done and usually the configuration dictates what method is selected. Some of these are outlined in a previous blog, Steel Wedge Manufacturing. The Steel Wedge we are focusing on in this conversation is required as part of a Fluorogold® or Teflon® Slide Bearing Assembly. Length is 20", Width is 14". Thickness starts at 1/2" and tapers down to 1/16". The unique size of this wedge dictates the manufacturing process.
The Steel Supply Company manufactures steel wedges both as standard stock sizes and made to order per customer's specifications. A wide range of tools and manufacturing processes are employed and, as with any process like this, costs are kept to the minimum that will allow a high-quality finished part. Nonetheless customers are frequently surprised at the difficulty of wedge manufacturing.
The Slotted Steel Shim and the Steel Wedge have some separate and some overlapping functions. The wedge has the ability to multiply force for lifting purposes. (To read more about the lifting force of the steel wedge, click here.
The askew head bolt is always and only used in connection with the wedge insert. This system is most commonly employed to secure relieving angles although it can be found in many other instances where steel members will be bolts to concrete.
In a previous article we described the process of making Made To Order Steel Wedges. See Steel Wedges - Made To Order This article will deal with the specifics of manufacturing the Russian Wedge, so called because of the unique Knock out Block at the large end. (see bottom right photo)
One of the most basic and yet most demanding of our product lines is the Steel Wedge. Once a fabricator or erector recognizes the need for a custom size wedge there are few shortcuts and rarely does the quantity required justify creating re-useable, hard tooling. (We do have 15 stock sizes - to view, click here)
